  • OTC30 Ice Cube Making Machine-Hot Sale


    OMT 3ton Ice Cube Making Machine is OMT hot sale product, it's very popular in Africa and Middle East. This model is quite good item for expanding production who has exsiting ice machines for 500kg to 1500kg, even it's good for beginners who expect to sell ice at 2000kg to 3000kg in a day. The machine adopts anti rust and corrosion free material- stainless steel 304 for its mainframe. Machine has a special ice outlet, which can be matched with ice packing system to pack the ice with plastic bag.

    Optional cube ice sizes: 22*22*22mm(Ice Freezing Time: 20minutes); 29*29*22mm(Ice Freezing Time: 23minutes).


    OMT 3ton Ice Cube Making Machine Technical Parameter:

    ModelOTC30
    Machine Capacity3,000KG/24HRS
    Ice Size22MM*22MM*22MM /29MM*29MM*22MM
    Cube Ice Weight Density500-550KG/CBM
    Cube Ice Grip Quantity12PCS
    Ice Harvest Time22*22MM (20Minutes)/29*29MM(23Minutes)
    Compressor Power15HP
    Compressor Model4NES-14 (Bitzer from Germany)
    Refrigerant(Gas)R22
    Cooling TypeWater Cooled
    Machine Control SystemGermany Siemens PLC
    Ice Discharging Motor1.1KW
    Circulating Water Pump0.55KW
    Cooling Water Pump1.1KW
    Cooling Tower Motor0.37KW
    Electricity Consumption80-85KWH/T
    Machine Dimension2100*1940*2050MM
    Machinery Unit Weight1350KG



    OMT OTC30 Cube Ice Machine Storage Ice Bin:









    OMT OTC30 Cube Ice Machine Working Video:








    OMT Ice Cube Making Machine Features:

    1) Strong and Durable parts.
         All compressor and refrigerant parts are world class.

    2) Low energy consumption.
        Energy consumption saving reaches more than 30% compare with traditional equipment.

    3)Siemens PLC Automatic Control System.
        Allow automatically adjust ice thickness, self-adapt to ambient temperature, automatic water supply, ice  freezing and ice falling.

    4)Special ice outlet.
        Ice discharge automatically without taking ice by hands, matched with ice packing system to pack the ice with plastic bags.

    5) High quality material.
        The mainframe structure are made of stainless steel 304 which is anti-rust and anti-corrosion.



    OMT 3ton Ice Cube Making Machine Pictures:

    Machine Front ViewMachine Side View
    Machine Section DrawingsIce Cube Machine and Cooling Tower
    Siemens PLC Automatic Control SystemAutomatically Ice Outlet and Padel Switch
    Cube Ice Application


    OMT Ice Cube Making Machine Series:

    Items

    OTC10OTC20OTC30OTC40OTC50OTC60OTC80OTC100OTC200
    Capacity(T/DAY)12345681020
    RefrigerantR22/R404A
    Compressor BrandBitzer/Bock
    Cooling WayWater Cooled
    Ice Maker Quantity(PCS)4812161824303636
    Compressor Power(HP)49/1214/1523/2028/2534/30502*28/253*34/30
    Ice Discharging Motor(KW)  0.750.751.11.11.11.11.1*21.1*22.2*2
    Circulating Water Pump(KW)0.370.550.550.750.751.11.51.52.2*2
    Cooling Water Pump(KW)0.751.11.11.51.52.22.22.25.5
    Cooling Tower Motor(KW)0.180.180.370.550.750.751.51.51.5
    SizeLength(MM)17001730/21502100/3158262031104000507058306250
    Width(MM)12301520/16401940/1950194019401940198019802310
    Height(MM)19702030/20302050/2030204020402190230023202470
    Machinery Unit Weight(KG)90012001350155017802100300039005500
    Cooling Tower Weight(KG)8T10T15T20T30T40T40T50T80T

    ⊙ Edible Ice Cube Size: 22MM*22MM*22MM or 29MM*29MM*22MM;
    ⊙ Supply Power: 380~420V, 50Hz, 3Phase; 220V, 60Hz, 3Phase; 380V, 60Hz, 3Phase; 440V, 60Hz, 3Phase
    ⊙ Standard Working Conditions: Input water temp: 21℃; Ambient temp: 25℃; Condensing temp: 40℃;
    ⊙ Model and specifications can be change without notice.



    Machine Configuration List:

    Component ItemBrand and Origin
    Compressor Bitzer/Bock
    PLC controller

    Siemens/Germany

    Oil separator  EMERSON/USA
    Electrical componentsLG (LS)/South Korea
    Solenoid valve  CASTAL/Italy
    High pressure controllerDANFOSS/Denmark
    Low pressure controllerDANFOSS/Denmark
    Expansion valveCASTAL/Italy
    CondenserJianguo/Xuemei
    EvaporatorOMEX/Guangzhou
