  • OTFS10 Seawater Flake Ice Machine


    OMT OTFS10 Seawater Flake Ice Machine is a small capacity 1000kg per 24hrs machine,this machine is usually used on deep-sea fishing boat and land.The flake ice evaporator is made of SUS316 material with strong seawater corrosion resistance.It is an indispensable good parter to marine fishing.


    OMT 1ton Seawater Flake Ice Machine Technical Parameter:


    Model NumberOTFS10
    Machine Capacity(kg/24hrs)1000
    Ice Thickness(MM)1.5~2.2
    Ice Freezing Time(MINUTE)1
    Evaporator Material SUS316L Stainless Steel,16Mn Steel
    Compressor BrandDanfoss
    RefrigerantR404A/R22
    Cooling WayWater Cooled
    Water inlet/outlet pipe size3/4"
    Supply Power220V~480V, 50Hz/60Hz, 3P
    Total Power6.5kw
    Compressor Power6HP
    Refrigerating capacity7.5kw
    Reducer power0.37kw
    Machinery Unit Size(MM)1310*950*890
    Machine Unit Weight(KG)256
    Warranty(MONTHS)12



    OMT Seawater Flake Ice Machine Features:

    1) Strong and Durable parts.
    All compressor and refrigerant parts are world first class.

    2) Low energy consumption.
    Energy consumption saving reaches more than 30% compare with traditional equipment.

    3) High quality material.
    The evaporator drum are made of tainless steel 316 material,which is anti-rust and anti-corrosion.

    4)PLC program Logic Controller.
    Provides multiple functions such as automatically turn on and shut down. Ice falling and Ice outgoing automatically,
    can be connected with automatic ice packing machine or convery belt.



    OMT 1ton Seawater Flake Ice Machine Pictures :

    1)Machine Side View


    2)Seawater Flake Ice Application



    OMT Seawater Flake Ice Machine Series

    ModelOTFS10OTFS30OTFS50OTFS80OTFS100
    Daily output1t/d3t/d5t/d8t/d10t/d
    Total power6.5kw15.3kw23.9kw32.2kw52.6kw
    Compressor power6HP15HP30HP40HP60HP
    Refrigerating capacity7.5kw22.5kw37.5kw58.4kw73kw
    Reducer power0.37kw0.37kw0.37kw0.75kw0.75kw
    Cooling styleWater-coolingWater-coolingWater-coolingWater-coolingWater-cooling
    Water inlet/
    outlet pipe size
    3/4"1/2"3/4"3/4"3/4"
    Unit dimension(mm)1310*950*8901500*1150*12501750*1550*16502530*1830*16802530*1830*1820
    Net weight256kg550kg780kg1100kg1320kg


    ⊙ Refrigerant:R22 or R404a
    ⊙ Supply Power: 380~420V, 50Hz, 3Phase; 220V, 60Hz, 3Phase; 380V, 60Hz, 3Phase; 440V, 60Hz, 3Phase;
    ⊙ Working Conditions: ambient temperature 28℃, Water inlet temperature 20℃,
         Evaporating temperature -25℃,Condensing temperature 40℃;

    ⊙ Model and specifications can be changed without notice.


    Machine Configuration List:


    Component ItemBrand and Origin
    Compressor Danfoss/Bitzer/Bock
    PLC controller

    Siemens/ Germany

    Oil separator  EMERSON/ USA
    Electrical componentsLG (LS)/South Korea
    Solenoid valve  CASTAL/Italy
    High pressure controllerDanfoss/ Denmark
    Low pressure controllerDanfoss/ Denmark
    Expansion valveCASTAL/Italy
    CondenserJianguo/Xuemei
    EvaporatorOMEX/Guangzhou
